Our range PW (Public Work) covers all the needs arising from public works such as the transport of aggregates, sands, asphalt agglomerates, earthworks, debris, rubble, gravel, etc …

With volumes from 24 to 35 m3

The Product Range Public work is available under Versions:

Catalog of Public Work

  • Models
  • Technical Data
  • Extras

OP24

  • Integral Aluminum Dump Truck 24 m3.
  • Straight or inclined door.
  • Available in: OMEGA and Ribs structure .

OP26

  • Integral Aluminum Dump Truck 26 m3.
  • Straight or inclined door.
  • Available in: OMEGA and Ribs structure .

OP30

  • Integral Aluminum Dump Truck 30 m3.
  • Straight or inclined door.
  • Available in: OMEGA and Ribs structure .

OP32

  • Integral Aluminum Dump Truck 32 m3.
  • Straight or inclined door.
  • Available in: OMEGA and Ribs structure .

OP35

  • Integral Aluminum Dump Truck 35 m3.
  • Straight or inclined door.
  • Available in: OMEGA and Ribs structure .

TECHNICAL DATA

DIMENSIONES


  • CLICK HERE TO DOWNLOAD THE TECHNICAL DRAWINGS OF PUBLIC BULK RANGE

CHASSIS


  • Aluminium chassis, straight shape.
  • Height of 5th Wheel: 1.200 mm.
  • 2” king-pin removable from the outside.
  • Double speed mechanical support legs.
  • Lateral anti-collision system.
  • Individual flaps.
  • Manual folding bumper.

AXLES AND SUSPENSION


  • 3 axles JOST for single wheel.
  • Brakes JOST Disc vía 2090.
  • Pneumatic suspension.
  • 6 BRIDGESTONE (mixed tread) tyres, 385/65 R 22,5”.
  • 6 steel rims, offset 120.
  • Automatic descent of suspension when tipping with possibility of cancelling from control box.
  • Handle for height control of suspension.

BRAKE INSTALLATION


  • EBS (2S/2M) with RSP function, sensor in one axle, and the three of them commanded.
  • Parking brakes actioned in two axles.

ELECTRICAL INSTALLATION


  • 5 functions lights.
  • 1 working light.
  • 4 lateral gauges type LED (2 each side).
  • 2 front white gauges (1 each side).
  • Electrical connections by 2x seven pins plugs: ISO 1185 and ISO 3731; and 1x 15 pins plug ISO 12098.

OMEGA BODYWORK


  • 4 mm thick front, H34 alu.
  • Sides made out of aluminium profiles and isolating air chamber, with progressive internal thickness from 6 mm below to 3 mm above.
  • 8 mm thick floor, H34 alu.
  • Internal reinforcement in the lower rear area in both sides with 4 mm sheet H34 alu.
  • Universal rear door with 4 mm thick sheet H34 alu, one hatch in right door, with one hasp + half hasp, tightening chain with crossbeam support, two lower handle spinning locks, two open door holders, double joint hinges, and internal aluminium bar.
  • Mechanical automatic lock with 4 hooks.
  • Anti-vibration hook.
  • Visibility markings.

HYDRAULICS


  • EDBRO cylinder with the first expansion chrome coated and the rest polished.
  • Hydraulic plug with cap (no pressure limitation valve installed).

ACCESSORIES


  • Wheel wrench.
  • 2 wheel chocks.
  • Naves covers.
  • Toolbox.
  • Fire-extinguisher holder (no fire-extinguisher included).
  • Water tank.
  • Rubber flap between beams.
  • Plate-holder.
  • Reverse gear acoustic signalling.
  • 1 rear pull shackle

EXTRAS

MODEL CHANGES


  • Change from TP-26-PI to TP-28.
  • Change from TP-26-PI to TP-30.
  • Change from TP-26-PI to TP-32.
  • Change from TP-26-PI to TP-35.

CHASSIS OPTIONALS


  • Different hitching height.
  • Pneumatic folding bumper.
  • Aluminium support legs.
  • Asphalt kit: (Diapress protection in aluminium, trimmed wheel fenders, rubber flaps, central tightening chain with support for crossbeam (without the crossbeam), switch in control box to lift automatically the suspension when tipping).

AXLES AND SUSPENSIONS OPTIONALS


  • Change of JOST axles for BPW or VALX DISCO.
  • JOST self steering axle.
  • Axles prepared for self inflating.
  • Self-inflating system.
  • ILVL pneumatic suspension.
  • First axle lift managed by EBS.
  • Second or third axle lift managed by EBS.
  • First and second axle lift managed by EBS with chassis selector for 2nd axis cancellation.
  • Third axle lift managed by EBS with pushbutton in control box or electric or pneumatic chassis tip with maneuver aid function and selector in chassis for the annulment of the 3rd lifting axle.
  • Change of tyres 6 BRIDGESTONE OBRA MT1 for 6 CONTINENTAL HTC1.
  • Change of tyres 6 BRIDGESTONE OBRA MT1 for 6 GOOD-YEAR MST II.
  • Change of tyres 6 BRIDGESTONE OBRA MT1 for 6 MICHELIN X WORKS.
  • Change of tyres 6 BRIDGESTONE ROAD R168 for 6 CONTINENTAL CHT3.
  • Change of tyres 6 BRIDGESTONE ROAD R168 for 6 GOOD-YEAR KMAX T.
  • Change of tyres 6 BRIDGESTONE ROAD R168 for 6 MICHELIN MULTI T.
  • Spare tyre Good Year MSTII or RHTII with steel rim.
  • Spare tyre Michelín XZY3 or XTE3II with steel rim.
  • Spare tyre CONTINENTAL with steel rim.
  • Spare tyre BRIDGESTONE with steel rim.
  • Change of 6 steel rims for 6 aluminium rims ALCOA MATE.
  • Change of 6 steel rims for 6 aluminium rims ALCOA LEVEL ONE.
  • Change of 6 steel rims for 6 aluminium rims ALCOA DURABRIGHT.
  • Change of 6 steel rims for 6 aluminium rims ACCURIDE EXTRA POLISH.
  • Change of 6 steel rims for 6 aluminium rims ACCURIDE ACCU-SHIELD.

ELECTRICAL INSTALLATION OPTIONALS


  • 1 working light with switch (max 2).
  • 1 working light type LED.
  • 5 functions lights type LED.

DOOR OPTIONALS


  • Change from universal door to swinging door (straight or inclinated).
  • Semi-watertight door for swinging door (not reccommended with hatch), (two lateral locks, three lower handle spinning locks, rubber seal in the box frame, no aluminium bar).
  • Hydraulic door (simple action cylinders, with double joint hinges, pneumatic locks with 4 hooks MUST BE ADDED ON TOP).
  • One additional hatch for universal door.
  • One additional hatch for swinging door
  • mi-tight gate for swing door (not recommended with portillion).
  • Two side closures, three lower handle closures, rubber gasket in the frame of the box, without round aluminum interior.
  • Hydraulic door (Single acting cylinders, with double hinged hinges).
  • Changing swing door inclined by a swinging door.
  • A swing gate for door.

CLOSURE OPTIONALS (4 HOOKS)


  • Change of mechanical lock for pneumatic lock with air pressure to open or close, managed from control box.
  • Pneumatic lock with air pressure to open or close, with pull handle in control box and pneumatic point in front of chassis.
  • Pneumatic lock with air pressure to open or close, with pull handle in control box and electrical point in front of chassis.
  • Pneumatic lock with air pressure to open or close, 3 positions switch (open/ close/auto).
  • Pneumatic lock with air pressure to open or close, 2 positions switch (close/auto).
  • Pneumatic locks with 4 hooks and 4 air chambers with pressure to open and pressure to close.
  • Mechanical or pneumatic lock in stainless steel (ONLY BAR AND HOOKS).
  • Mechanical lock in stainless steel (COMPLETE INCL. STEERING MECHANISM).
  • Hasps and handle spinning locks in stainless steel.

HYDRAULIC OPTIONALS


  • Change cylinder EDBRO to HYVA or OLESA.

CANVAS OPTIONALS


  • Cramaro canvas type C with handle, hooks and continuous rail.
  • Electric system with switchboard in chassis for Cramaro type C canvas.
  • Remote control for Cramaro canvas.
  • Manual BOTERO canvas by rail.
  • Electric system with switchboard in chassis for BOTERO canvas.
  • Remote control for BOTERO canvas.
  • Canvas with lateral closure system with 3 cross strips with tighteners and 1 .central bar, 3 folding canvas-holders, 3 crossbeams between laterals, 2 tightening chains, front balcony and internal steps.
  • Install front balcony with access stair and walkway.
  • One additional crossbeam with supports and tightening chain.
  • Hooks for mesh (mesh not included).

PAINT OPTIONALS


  • Paint bodywork and chassis in different colors.

ACCESSORIES


  • Change of fire-extinguisher holder from 6-9 Kg.. to 9-12 Kg.
  • Additional 9 Kg. fire-extinguisher holder.
  • Toolbox of 1000.
  • Odometer.
  • Manometer for load control.
  • Pneumatic installation for weight in front of chassis.
  • INFO-TIM.
  • Water tank.
  • Fixed ladder in left lateral.
  • Simple ladder at the front (no balcony).
  • 3 m. hand ladder.
  • DO NOT INCLUDE 4 m hand ladder.
  • Aluminium air tank.
  • Brake pads wear indicator kit.
  • Washing center with 10 or 20 m reel.
  • Vibrator.
  • Brush and shovel holder.
  • OPTITURN/ OPTILOAD.
  • Cover laterals with 4 mm thick sheet.
